Description
Technical Parameters
Electric Water Foam Fire Cannon
This fire monitor can be flexibly applied to various types of fires, such as building fires, oil tank fires, chemical plant fires, etc. It can spray water to cool down the fire source, and at the same time cover and isolate the fire source with foam to prevent the fire from spreading. In addition, due to the adsorption function of the foam, it can wrap the burning material to achieve the effect of suffocating and extinguishing the fire.
The dual-purpose fire monitor with foam and water is simple in structure, easy to operate, wide in spraying range and long in spraying distance. It is one of the necessary equipment for fire fighting and rescue by the fire department, and it is also the key equipment for ensuring social safety.
|
Model Number
|
PLKD8/24-A
|
PLKD8/32-A
|
PLKD10/48-A
|
PLKD10/64-A
|
PLKD10/80-A
|
|
Flow Rate
|
1440 LPM | 1920 LPM | 2880 LPM | 3840 LPM | 4800 LPM |
|
Working Pressure
|
8 Bar
|
8 Bar
|
10 Bar
|
10 Bar
|
10 Bar
|
|
Water Max. Reach @ 8 bar
|
55 meters
|
60 meters
|
65 meters
|
75 meters
|
85 meters
|
|
Foam Max. Reach @ 8 bar
|
42 meters | 48 meters | 55 meters | 70 meters | 80 meters |
|
Max Range Of Monitor
|
-90° to +90° Vertically, 340° Rotation,other degree available
|
||||
|
Power Supply
|
DC 24V is standard
|
||||
|
Power Consumption
|
24V @ 7.5A
|
||||
|
Waterway Size
|
2.5" (65mm)
|
2.5" (65mm)
|
3" (80mm)
|
3" (80mm)
|
3" (80mm)
|
|
Monitor Outlet
|
2.5" (65mm)
|
3" (80mm)
|
|||
|
Monitor Inlet
|
Flange 4" ANSI 150# is standard,other size and standard available
|
||||
|
Material
|
Monitor - SS304 Stainless Steel
Nozzle - Hard coated anodized aluminium alloy (SS304 optional)
|
||||
|
Control System
|
ICS-01 or VMCS-01
|
||||
FAQ：
Q:How to mail the samples?
Small samples are usually sent by express (DHL, UPS, FEDEX, TNT). If the buyer has other opinions, both parties can discuss with each other.
Q:What is your term and payment?
Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.
Q:Do you offer guarantee for the products?
Yes, we offer 1 year warranty to our products.
Recommend Product
Hot Tags: electric water foam fire cannon, China, manufacturers, suppliers, wholesale, price, Fixed Remote Control Foam Monitor, RC Fire Fighting Monitor, Stainless Steel Water Cannon, Electric Explosion Proof Fire Monitor, Stainless Steel Fire Monitor, Remote Operated Fire Water Monitors
- SS304 Stainless Steel construction;
- Constant flow rate,24/32/48/64/80 LPS;
- Vertical travel of 180°,from -90° to +90°;
- 340° rotation horizontally;
- Available for water and foam both;
- Electric driver and control box are waterproof;
- Available for Self-Inducting;
- Optional power supply 12V/24V DC(optional),or 100-230AC.
