PSKD 20-30 BS this type fire monitor is remote controlled, can be installed in an unconvenient for manual control. It can be applied in fire rescues, fire protection and safety. Electronic Control Fire Monitor for Firefighting is made of aluminium alloy.
Model Number | PSKD8/20W-B | PSKD8/30W-B | PSKD8/40W-B | PSKD8/20-30-40W-B |
Flow Rate | 1200 LPM | 1800 LPM | 2400 LPM | 1200-1800-2400 LPM Selectable |
Working Pressure | 8 Bar | 8 Bar | 8 Bar | 8 Bar |
Max. Reach @ 8 bar | 50 meters | 60 meters | 65 meters | 65 meters |
Max. Fog Angle | 120° | |||
Max Range Of Motion | -90° to +90° Vertically, 340° Rotation,other degree available | |||
Turing Speed | 24°/Second rotation,10°/Second vertical | |||
Power Supply | DC 24V is standard | |||
Power Consumption | ≤200W | |||
Waterway Size | 2 1/2" (65mm) | |||
Monitor Outlet | 2 1/2" (65mm) NH male thread | |||
Monitor Inlet | Flange 2.5" ANSI 150# is standard,other size and standard available | |||
Material | Monitor & Nozzle- Hard coated anodized aluminium alloy | |||
FAQ:
Q: How many agents the company currently has overseas
Currently we have 2 agents abroad. One in Israel and one in Maldives.
Q: Is there a product quotation?
Yes,you can send us the inquiry first.We will send your quotation sheets according your inquiry.
Q: What about the lead time?
Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
Hot Tags: aluminum alloy fire monitor for fire rescuse, China, manufacturers, suppliers, wholesale, price, Electrical Fire Fighting Water Monitor, Explosion Fire Monitor, Breeching Inlet Valve, Electric Fire Water Monitor, Electric Explosion Proof Fire Monitor, Automatic Fire Water Monitor
1) Hard coated anodised aluminum alloy construction, long expendency;
2) Constant nozzle,while this nozzle can change into different flow rate, like 1800LPM;
3) Power supply type is selectable, either 12V/24V DC or 100-230AC;
4) Electric driver and control unit box are waterproof.
