Products Description
forede® explosion-proof remote control monitor is a specialized electronic device that is designed to provide monitoring and control functions in hazardous areas such as oil and gas refineries, chemical plants, and other locations where flammable gases or liquids may be present. The monitor is explosion-proof, meaning that it is constructed in such a way as to prevent the ignition of explosive gases or vapors in the surrounding environment. It is also remote-controlled, meaning that it can be operated from a safe distance using a variety of control options such as wired or wireless connections. The monitor can provide real-time feedback on critical parameters such as temperature, pressure, and flow rates, and can be programmed to alert operators to potential safety hazards.
Products Parameters
|
Model Number
|
PSKD50EX-A
|
PSKD60EX-A
|
PSKD80EX-A
|
|
Flow Rate
|
3000 LPM
|
3600 LPM
|
4500 LPM
|
|
Working Pressure
|
8.5 Bar
|
9.5 Bar
|
10.5 Bar
|
|
Max. Reach
|
75 meters
|
75 meters
|
80 meters
|
|
Max. Fog Angle
|
120°
|
||
|
Max Range Of Motion
|
-45° to +90° Vertically, 360° Rotation,other degree available
|
||
|
Turing Speed
|
7°/Second rotation,7°/Second vertical
|
||
|
Power Supply
|
DC 24V is standard
|
||
|
Power Consumption
|
Max. 195W
|
||
|
Waterway Size
|
2.5"(65mm)
|
3"(80mm)
|
3"(80mm)
|
|
Monitor Outlet
|
2.5" (65mm) NH
|
||
|
Monitor Inlet
|
Flange 4" ANSI 150# is standard,other size and standard available
|
||
|
Material
|
Monitor - SS304 stainless steel is standard,SS316 is available
Nozzle - Hard coated anodized aluminium alloy
|
||
|
Control System
|
ICS-EX-01 or VMCS-01
|
||
