Technical Parameter
| Model |
PLKD10/64G-A
|
PLKD10/80G-A
|
| Flow Rate |
3840 LPM
|
4800 LPM |
|
Water Max. Reach
|
75 meters
|
85 meters
|
|
Foam Max. Reach
|
70 meters | 80 meters |
| Working Pressure | 10 Bar | 10 Bar |
|
Max Range Of Monitor
|
-60° to +90° Vertically, 340° Rotation,other degree available
|
|
|
Power Supply
|
DC 24V is standard
|
|
|
Power Consumption
|
≤200W | |
|
Waterway Size
|
3" (80mm)
|
|
|
Monitor Outlet
|
3" (80mm) NH
|
|
|
Monitor Inlet
|
Flange 4" ANSI 150# is standard,other size and standard available
|
|
|
Material
|
Monitor - SS304 Stainless Steel
Nozzle - Hard coated anodized aluminium alloy (SS304 optional)
|
|
|
Control System
|
ICS-EX-01 or VMCS-01
|
|
An Explosion Proof Remote Control Fire Water Foam Monitor is a high-tech firefighting tool that can be used to extinguish fires in hazardous locations. Built with special materials and designed to withstand extreme temperatures and pressure, the monitor can spray water or foam from a safe distance, allowing firefighters to stay out of harm's way. Equipped with a remote control system, the monitor can be operated from a safe location, enabling firefighters to react quickly to emergencies and minimize risks. This advanced firefighting technology has proven to be highly effective in preventing fires from spreading and saving lives. With the constant advancement in technology, we can look forward to more innovative solutions in the firefighting industry.
Where is Explosion Proof Remote Control Fire Water Foam Monitor Used?
Explosion Proof Remote Control Fire Water Foam Monitor is widely used in places that require a high level of safety, such as chemical plants, oil refiners, and petrochemical facilities. The monitor is designed to withstand explosive environments and to spread foam and water to control fires, mitigate explosions, and protect people and property.
In addition to its primary firefighting function, Explosion Proof Remote Control Fire Water Foam Monitor can also be used for cooling and decontaminating hazardous areas. Its remote control feature allows operators to stay at a safe distance while controlling the monitor's movements and flow rate, enhancing their safety and reducing the risk of accidents.
Overall, the Explosion Proof Remote Control Fire Water Foam Monitor is an important tool for maintaining a safe and secure work environment and preventing disasters. Its deployment can boost confidence among workers, improve productivity, and give the community peace of mind.
