The forede® Brand The Self-Inducting Foam Monitor Barrel Nozzle is an advanced firefighting tool designed to deliver high-performance foam discharge with exceptional efficiency and reliability. Engineered for ease of use and durability, this nozzle plays a vital role in quickly controlling and extinguishing fires, especially in industrial and hazardous environments.
Featuring a self-inducting mechanism, the nozzle effortlessly mixes foam concentrate with water, creating a consistent and effective foam solution that enhances fire suppression capabilities. Its robust construction ensures long-lasting operation even under demanding conditions, while the ergonomic design allows firefighters to maneuver and adjust the foam flow with precision and confidence.
Ideal for use in a variety of applications such as chemical plants, oil refineries, airports, and storage facilities, the Self-Inducting Foam Monitor Barrel Nozzle empowers firefighting teams to act swiftly and decisively. By providing a reliable and efficient foam delivery system, it supports safer environments and helps protect lives and property effectively.
Overall, this innovative nozzle embodies excellence in firefighting technology, combining smart design with powerful functionality to meet the highest standards of safety and performance. It is a valuable asset for any fire protection setup, fostering a proactive approach to fire safety and emergency response.
01
Self-Inducting Foam Aspiration Pipe
The MSQ040 nozzle comes with 1.5 meters PU flexible hose with cam-lock coupling for inducting foam concentrate, it then introduces sufficient air for mixing with foam solution, to produce foam and deliver it.
02
Compact, Solid, Straight Steam With Far Reach
With bulid-in stream shaper, Long enough straight barrel style MSQ040 monitor water foam nozzle forming a tight, solid straight water or foam steam to have an far reach.
03
Painted Stainless Steel And Anodized Aluminum Alloy
The foam nozzle barrel body adopts stainless steel 304 and aluminum alloy stream shaper, which is durable, pressure-resistant and anti-corrosion for corrosive and non-corrosive applications.
Durable heavy duty stainless steel 304 with aluminum alloy construction
Simple,rugged nozzle with superior stream quality and reach.
Powerful,steady, concentrated,solid stream.
Customized to meet different flow rate @ different working pressure.
Extremly low maintenance, high quality components.
Self-inducting foam tube optional.
Suitable for most of fire monitor assembly of forede brand.
Build-in shape for incredible reach and stream quality.
Simply and qucikly connect with foam tube for inducting foam concentrate.
Style Number : MSQ040
Monitor Nozzle Material: Stainless Steel 304 and Aluminum Alloy
Pattern: Straight Steam
Monitor Nozzle Type: Foam Aspiration Pipe
Max.Flow Rate: 2400 LPM
Media: Water or Foam
Self-Inducting Foam Function: Optional with 1.5 meters PU flexible hose with Cam-lock coupling
Foam Proportion: 3% or 6% Optional
Barrel Color: White/Red/Yellow Optional
Control Type: Manual control.
Inlet Size: 2.5 '' NH Female
Application: For fire monitor,for fire fighting.
Suitable Monitor Assembly: TFS1,TFS2,WFS1,WFS2,EFS1,EFS2,XFS1,XFS2
| Surface Finishing: | Painted Stainless steel 304 with Anodized Aluminum Alloy. | ||||||
| Flow Rate (LPM): | 1440/1920/2400 LPM Constant Flow. | ||||||
| Rated Working Pressure: |
0.8Mpa/8 Bar/115psi. |
||||||
| Max Working Pressure: | 1.38Mpa/13.8bar/200 psi. | ||||||
| Inlet Size: | 2.5" NH Female (Other coupling style is acceptable). | ||||||
| Max.Reach(Water): |
55 meters @1440LPM,60 meters @1920LPM ,65 meters @2400lpm (@ 30 Degree,1.2 Meters To the Ground.Wind Speed ＜2m/s). |
||||||
| Max.Reach(Foam): | 42 meters @1440LPM,48 meters @1920LPM ,55 meters @2400lpm (@ 30 Degree,1.2 Meters To the Ground.Wind Speed ＜2m/s). | ||||||
| Foaming Expansion | ≥ 6 times, upon foam type | ||||||
Note: The throw range of the self-inducting air-aspirating foam monitor nozzle is 10% shorter than the specified range in the table
Petrochemical
Fuel/Oil Storage Tank Area
Oil Rig
Airport & Hanger
Fire & Rescue Services
Fire Truck
Wildland Forest
Marine & Offshore
It is a firefighting device designed to efficiently mix foam concentrate with water and project the foam mixture onto a fire. This nozzle is widely used for fire suppression in various industrial and commercial settings.
The nozzle automatically draws foam concentrate into the water stream without requiring an external pump. This creates a consistent foam solution, enhancing firefighting effectiveness.
It offers quick setup, ease of operation, effective foam delivery, and improved safety for firefighters by enabling better fire suppression from a distance.
Yes! The nozzle is designed for quick installation by 2.5" NH female and user-friendly operation, suitable for all fire monitor with 2.5" NH male outlet.
Yes, it is primarily used for Class A and Class B fires involving flammable liquids or combustible materials, making it versatile for various firefighting scenarios.
⚠️
- Designed for use with fire monitors – not suitable for handheld use
- See Instruction before use.
- Scheduled maintenance is necessary.
- It's used for Class A/B Fire.
3
Materials
Lightweight anodized aluminum alloy
Wear-resistant brass alloy
Anti-corrosion stainless steel 304/316
3
CONTROL TYPES
Manual Control
Electric Remote Control DC24V
Explosion-proof Electric Remote Control DC24V / AC 220V
5
SERIES
Smoothbore,Stacked Tips & Deluge Tip
Constant Flow
Selectable Flow
Automatic(Constant Pressure) Nozzle
Monitor Foam Nozzle
