Products Description
Overview
The forede® PCL tank foam chamber is designed to introduce expanded foam directly onto the surface of a flammable or combustible liquid for fire extinguishment and/or vapor suppression. Minimizing submergence and agitation increases the effectiveness of the foam blanket, resulting in more efficient operation, and superior extinguishing capabilities. Foam chambers have the added advantage of directing all their flow directly onto the product surface regardless of weather conditions, for the most effective utilization of foam resources.
Features
Product Name: Tank foam chamber
Flow Rate: 240LPM, 480LPM, 960LPM, 1440 LPM
Material: Carbon Steel
Expansion: Low expansion, ≥ 5 Times
Working Pressure: 0.7MPa
Products Paremeters
forede® tank foam chamber with different size and standard for option:
| Model |
Installation |
Flow Rate |
Inlet Size |
Outlet Size |
|
PCL4 |
Vertical |
240 LPM |
50mm (2'') |
80mm (3") |
|
PCL8 |
Vertical |
480 LPM |
65mm (2.5") |
100mm (4") |
|
PCL16 |
Vertical |
960 LPM |
80mm (3") |
150mm (6") |
|
PCL24 |
Vertical |
480 LPM |
100mm (4") |
200mm (8") |
FAQ
Q: What is a tank foam chamber?
A tank foam chamber is a device that produces foam by mixing a foaming agent with water. It is installed on top of a storage tank, and in the event of a fire, the foam is discharged from the chamber to cover the surface of the liquid, extinguishing the fire.
Q: What is 25% liquid drain time of tank foam chamber?
The forede® PCL tank foam chamber 25% liquid drain time ≥ 120 s whcih could reach a good performance.
Q: How does a tank foam chamber work?
Tank foam chamber works by mixing a foaming agent with water and spraying the mixture onto the surface of the liquid in the storage tank. As the foam is produced, it blankets the surface of the liquid, extinguishing the fire.
Q: What is split deflector on the tank foam chamber?
Foam chamber split deflector is a device that is used to create a uniform distribution of foam in the fire suppression system, control over the distribution of foam, ensuring that it covers a wide area, and reaches all the critical locations in the building.
Q: How often should a tank foam chamber be tested?
Tank foam chambers should be tested regularly to ensure they are functioning properly. The frequency of testing will depend on the regulations and guidelines of the local jurisdiction, but it is typically recommended to test foam chambers at least once a year.
