The spray range of the deluge system is controlled by the deluge valve, and a large area of water is sprayed immediately after the system is started. It is suitable for special dangerous places where large area spraying water is required to quickly extinguish fires.
In addition, the deluge valve also plays a very important role as the system alarm control valve in the water spray fire extinguishing system.
Material | Body | Ductile iron |
Diaphragm | NBR rubber | |
Pipes | Stainless steel 304 pipe,cooper pipe | |
Ball valve & strainer & check valve | Brass | |
Water motor gong | Stainless steel 304 | |
Working pressure | 12 bar | |
Sealing testing pressure | 24 bar | |
Applicable temperature | 4°C to 70°C | |
Installation | Vertically or horizontally | |
Flow switch contact capacity | DC24V,0.5A | |
Solenoid valve Voltage | DC24V | |
Connection | Flange × Flange | |
Available Size | DN50 thru DN250 (2" thru 10") | |
Hot Tags: flanged deluge valve with stainless steel pipe, China, manufacturers, suppliers, wholesale, price, Flange Type Dry Alarm Valve, Deluge Valve For Fire Protection, Groove End Deluge Valve, Groove Type Deluge Valves
1) Ductile iron construction valve body,less weight and extra strength.
2) Available for electric operation,hydraulic operation,manual operation.
3) The all moving parts can be serviced without removing the valve from the installed position.
4) Simple design for easy installation and operation.
5) Vertical or horizontal installation.
6) CCCF certificated.
